PU panels — polyurethane (PUF) sandwich panels — are the premium insulated panels for cold storage, clean rooms, and prefab buildings where maximum insulation in minimum thickness is required. As a top PU panel manufacturer, Thermo Master supplies PUF panels from our factory on Katar Band Road, near Thokar Niaz Baig, Lahore, delivering across Pakistan since 2017.
With the lowest thermal conductivity of any panel core (0.022 W/mK), a 100 mm PU panel insulates like 150 mm of EPS — critical where every inch of cold-room space earns money.
What PU Panels Are and How They Work
A PU sandwich panel is polyurethane foam injected between two PPGI steel facings, bonding into a single rigid unit. The foam’s fine closed-cell structure delivers R-6.5+ per inch — the highest of any sandwich panel. Panels come 30–200 mm thick with cam-lock joints for airtight cold-room assembly, 1 m wide, up to 12 m long.
Specifications
| Property | Specification |
|---|---|
| Core material | Polyurethane foam (PUF); PIR fire-grade on request |
| Core density | 38–42 kg/m³ |
| Thermal conductivity | 0.022 W/mK |
| Thickness | 30 / 40 / 50 / 60 / 75 / 80 / 100 / 120 / 150 / 200 mm |
| Steel facings | PPGI, 0.40–0.50 mm |
| Effective width | 1000 mm |
| Length | Up to 12 m |
| Joint | Cam-lock (cold rooms) / tongue & groove |
Insulated Panels Comparison — EPS vs XPS vs PU
| Factor | EPS Panel | XPS Panel | PU (PUF) Panel |
|---|---|---|---|
| Insulation per inch | Good (R-4 per inch) | Better (R-5.9 per inch) | Best (R-6.5+ per inch) |
| Core strength | Moderate | High | High |
| Water resistance | Good | Excellent | Excellent |
| Fire performance | FR grade available | FR grade available | Best (PIR option) |
| Cost | Most economical | Mid-range | Premium |
| Best for | Prefab rooms, sheds, warehouses | Cold rooms, damp areas | Cold storage, clean rooms |
Applications in Pakistan
- Cold storage & freezer warehouses — the industry standard panel
- Clean rooms — pharma, food processing, electronics
- Dairy & meat processing plants
- Supermarket cold sections & ripening chambers
- Prefab offices where premium finish matters
Price Table: PU Panel Prices in Pakistan
| Thickness | Indicative Rate (per sq ft) | Best For |
|---|---|---|
| 50 mm | Rs. 650–850 | Chillers, clean rooms |
| 75–80 mm | Rs. 800–1,050 | Cold storage |
| 100–150 mm | Quoted per project | Freezer warehouses |
PU panels are a project-priced product — share drawings or room dimensions on WhatsApp at 0333-4673836 for a detailed quotation.
Why Choose Thermo Master — A Top PUF Panel Supplier
- Factory-direct PUF panels with consistent 38–42 kg/m³ core density
- Cam-lock panels for airtight cold-room assembly
- EPS, XPS and PU panels from one manufacturer — unbiased advice
- 500+ completed projects since 2017
- Nationwide delivery with erection guidance
What Our Customers Say
Hamari service use ki? Google par apna review Urdu ya English me likhein — aapki raaye hamare liye qeemti hai.
FAQs
PU vs PIR — what’s the difference? PIR is a fire-enhanced polyurethane with better fire ratings. Specify PIR for buildings needing strict fire compliance.
How long do PU panels last? 20–25 years in cold storage service with sealed joints.
Do you install cold rooms? We supply panels with erection guidance and can arrange installation teams for major cities.
Get a Free Quote
Send drawings or dimensions on WhatsApp at 0333-4673836 or email info@thermomaster.pk. Full range at https://thermomaster.pk.
